    220v Bottom Discharged Three Roll Mill For Soap Making Machine

    Ask Lasest Price
    Brand Name : LIMAC
    Supply Ability : 5 Set/Sets per Month
    Price : $49,000.00/sets 1-1 sets
    • Product Details
    • Company Profile

    220v Bottom Discharged Three Roll Mill For Soap Making Machine

    Bottom discharged three roll mill from soap making machine
    Product Description
    220v Bottom Discharged Three Roll Mill For Soap Making Machine
    HIGH PRECISION DOUBLE SCRAPER BOTTOM- DISCHARGE ROLLER CAN MAKE PURE VEGETABLE OIL SOAP NOODLES TRANSPARENT ONCE.
    This bottom discharged mill with three rolls and two scrapers are design for professional soap producers. The soap particle size can reach 0.05 mm after milling. The size of milled soap is uniformly distributed, that means 100% of fficiency, The 3 rolls, made from stainless alloy 4Cr, are driven by 3 gear reducers with their own speed. The gear reducers are supplied by SEW, Germany. The clearance between rolls can be adjusted independenty; the adjusting error is 0.05 mm max. The clearance is fixed by shrinking sleeves supplied by KTR, Germany, and set screws.
    The smashed soap will form flakes by pressure since the mill is bottom discharged. The milling process is no pollution to the environment, low noiso, no dropping of soap. The mill is applcable to processing tlilet soap, low-fat soap and translucent soap.
    This mill now is in the top of similar machine in the world.
    PRODUCT SPECIFICATIONS
    No
    Item
    Data
    1
    fast Power
    18KW
    2
    Middle power
    15 kw
    3
    low power
    7.5kw
    MECHANCAL CONIGURATION:
    Germany SEW gear reducers, speed ratio is 203:75:29 are used. German KTR universal coupling and expanding sleeve are adopted. The outside diameter of the roller is 405 mm, the effective length is 900 mm, and the wall thickness is 60 mm. There is a cooling device inside the rller, which is sealed by a mechanical seal. The three rollers are made of 4Cr stainless alloy, and after heat treatment, the surface hardness reaches 72 degree Shore.
    ELECTRIC MOTORS:
    Fast roll 18.5 kW / Middle roll 15 kW / Slow roll 7.5 kW
    Details Images
    220v Bottom Discharged Three Roll Mill For Soap Making Machine
    220v Bottom Discharged Three Roll Mill For Soap Making Machine
    220v Bottom Discharged Three Roll Mill For Soap Making Machine
    220v Bottom Discharged Three Roll Mill For Soap Making Machine
    220v Bottom Discharged Three Roll Mill For Soap Making Machine
